16mm press button metal ip67 ring led power symbol switch

16mm press button metal ip67 ring led power symbol switch

Name: 16mm press button metal ip67 ring led power symbol switch
Brand: HBAN HONGBO PUSH BUTTON SWITCHES
Availability: InStock
Rating: 5 (1 reviews)

1. key word: 16mm metal press button
2. MOQ: 40 piece
3. Head material: metal
4. Head type: flat head, high head, dot LED, high head dot LED, ring LED, high head ring LED, power symbol, high head power symbol, ring and power symbol, high head ring and power symbol
5.Application areas: machinery, industrial equipment, food, aviation, new energy, medical, automation, cruise ships and other industries
6. Advantage: support custom head logo LED
7. Whether to support electroplating：Yes;
8. Shipping meth

INQUIRY

Description

★Latest news

From 4pm to 8pm every Wednesday(China time), Live broadcast will be held to explain the functions of metal buttons, plastic buttons, micro buttons, signal lights, buzzers and other products.The specific time of live broadcast will be announced later.Follow our official social media for more information.

★Product parameters

Legend	model	Description	size
	HBS1-AGQ16F-□■/J/◎	●Mounting hole size: Ø16mm ●Head type: Flat head/High head ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Housing material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16H-□■/J/◎
	HBS1-AGQ16F-□D■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Dot LED/High head dot LED ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White(two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16H-□D■/J/◎/▲/△
	HBS1-AGQ16F-□E■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Ring LED/High head ring LED ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White (two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16H-□E■/J/◎/▲/△
	HBS1-AGQ16F-□DT■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Power symbol/High head power symbol ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White (two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16H-□DT■/J/◎/▲/△
	HBS1-AGQ16F-□ET■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Ring and power symbol/High head power symbol ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White (two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16H-□ET■/J/◎/▲/△
	HBS1-AGQ16F-□P■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Big button face ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White (two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16F-□SP■/J/◎/▲/△	●Mounting hole size: Ø16mm ●Head type: Flat head(Custom symbol) ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Momentary/Latching ●Lamp bead color: Red/Green/Yellow/Orange/Blue/White (two colors and three colors are available) ●Shell material: Nickel-plated brass/Stainless steel ●Waterproof grade: IP67
	HBS1-AGQ16F-□TS/J/◎/★	●Mounting hole size: Ø19mm ●Head type: Emergency stop switch ●Switch value: 5A/250V AC ●Switch combination: 1NO1NC /2NO2NC ●Operation type: Press the lock ●Shell material: Zinc alloy ●Waterproof grade: IP65

★FAQ

Q: Do you have a catalog? Can you send me the catalog to me for checking them ?
A: Yes , We have product catalog.Please contact us on line or send an Email to hb at hban.cc for send-ing the catalog.

Q: Can you provide samples ?
A: Yes,we can provide samples.
we will collect samples fee(1-3pcs)and you have to pay for the shipping cost.when you place normal order.we will refund the samplefee for you.

Q: What kind of payment do you accept ?
A: We accept T/T(Wire transfer),Western Union and Paypal,credit card. Please be sure that we can re-ceive the same amount of the Invoice.

Q: What about your delivery time?
A: We have a lot of products in stock.We can send the stock products in 3 work days.
If without stock,or stock is not enough, we will check the delivery time with you.will update to you within 48 hours.

Q : How to ship my order ? Is it safe?
A: For small package, we will send it by Express, such as DHL,FedEx,UPS,TNT.That’s a Door to Door service.For big packages, we will send them by Air or By sea.We will use good packing and ensure the safet-y.We will be responsible to any product damage caused on delivery.
